Tenda A301V2.0

”

TENDA A301V2.0 DESCRIPTION

A301    /    EXTENDER    /    300MBPS WIFI REPEATER

A301 is an N300 Mini WiFi repeater dedicated to two-story houses, villas, and multi-room houses with an area of over 120 square meters. It offers up to 300 Mbps data rate on the 11n band. With two external Omni-directional antennas, A301 can provide larger WiFi coverage, as well as an extremely fast data rate, satisfying applications such as the playback of 1080P HD videos, and massively multiplayer online games, and high-speed download. With the upgrade Setup Wizard, it only takes you three steps to configure your repeater, which is easy to use. A301 also works better with other brands’ WiFi routers available on the market. For whole-home WiFi coverage, A301 is your best choice.

Selling Points

A301 / N300 Mini WiFi Range Extender

Fast speed and wide coverage

A301 is designed for two-story houses, villas, as well as 120m or larger apartments.

With 2 external Omni-directional antennas, A301 offers a data rate of 300 Mbps, a wider

WiFi coverage, and faster transmission speed to ensure superior performance in

video playback, fast-speed download, and big online games.

Stylish design, smaller, fresher, and more elegant

The streamlined and dynamic line pattern design endows A301 with a stylish appearance.

Mini-size design makes A301 look compact and elegant.

Swift switchover between the Repeater

and AP modes

You can switch between Repeater mode and AP mode as needed.

Repeater mode: A301 can expand WiFi coverage by bridging the upstream router’s

WiFi signal, and allows wired devices to be connected to its LAN port to access the

internet; AP mode: connect an Ethernet cable with internet connectivity to the LAN

port of A301 to turn it into an AP.

Intuitive signal LED to indicate the optimal

repeater location

The Signal LED tells the best repeater location.

Blue: good signal strength

Red: poor signal strength

Off: no signal

Compatible with any WiFi router

A301 can work well with any WiFi router and WiFi DSL modem router available on the

market, outshining most the repeaters.

Specification

Port

1 * 10/100M Ethernet Port (RJ45)

Button

Reset, WPS

LED indicator

1 * Signal LED

1 * WPS LED

1 * Power LED

Power Supply

5V 1A, built-in

Plug Type

EU?UK?US?AU?AR

Power Consumption

No-load: 1.6W, Full-load: 3.8W

Standard&Protocol

IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n on 2.4 GHz

Data Rate

802.11b: 11 Mbps

802.11g: 54 Mbps

802.11n: 300 Mbps

Frequency Band

11n: 2.412-2.484 GHz

Transmit Power

< 20 dBm (EIRP)

Antenna

2 * External 3dBi Omni-directional antenna (non-detachable)

Channel

11n: 20/40MHz by default

Operating Mode

Repeater Mode

AP Mode

Wireless security protocol

Encryption mode: Mix WPA-PSK/WPA2-PSK

WPA algorithm: TKIP&AES

DHCP Server

Support

System Tool

Firmware upgrade, Restore factory settings, Login password, and Reboot

Dimension

80mm * 58mm * 48mm

Temperature

Operating temperature:0ºC~40ºC

Storage temperature:-40ºC~70?

Humidity

Operating humidity:(10 – 90)% RH, non-condensing

Storage temperature:5%~90%RH, non-condensing

Certification

CE?FCC?RoHs”
