Description
”
- 2×2 high-efficiency Wi-Fi 6
- 5 GHz band 2×2 MU-MIMO and OFDMA with a radio rate of 1.2 Gbps
- 4 GHz band 2×2 MIMO with a radio rate of 300 Mbps
- Gigabit Ethernet, powered with 802.3af PoE (PoE injector not included)
- Compatible with UAP-nano HD covers and recessed mounting bracket
PRODUCT SPECIFICATIONS
Model No | U6-LITE |
2.4 GHz Speed | 300 Mbps |
5 GHz Speed | 1201 Mbps |
Dimensions | Ø160 x 32.65 mm (Ø6.3 x 1.3?) |
Environment | Indoor/Outdoor |
Ports | (1) 10/100/1000 Ethernet Port RJ45 |
PoE Mode | 802.3af PoE; 48V, 0.32A |
Mechanical | |
Dimensions | Ø160 x 32.65 mm (Ø6.3 x 1.3?) |
Weight | Without Mount: 300 g (10.6 oz) With Mount: 315 g (11.1 oz) |
Enclosure Characteristics | Polycarbonate 110 and ADC12 Die Casting |
Mounting Characteristics | Polycarbonate, SGCC Steel |
Hardware | |
Processor Specs | 880 MHz MIPS 1004 KEc |
Memory Information | 256 MB |
Management Interface | Ethernet In-Band |
Networking Interface | (1) 10/100/1000 Mbps Ethernet RJ45 |
Buttons | Factory Reset |
LEDs | White/Blue |
Power Method | 802.3af PoE, Passive PoE (48V) |
Power Supply | 802.3af PoE; 48V, 0.32A PoE Adapter (Not Included) |
Supported Voltage Range | 44 to 57VDC |
Max. Power Consumption | 12W |
Max. TX Power 2.4GHz 5GHz |
23 dBm 23 dBm |
MIMO 2.4GHz 5GHz |
2 x 2 2 x 2 |
Throughput Speeds 2.4GHz 5GHz |
300 Mbps 1201 Mbps |
Antenna Gain 2.4GHz 5GHz |
2.8 dBi 3 dBi |
Operating Temperature | -30 to 60° C (-22 to 140° F) |
Operating Humidity | 5 – 95% Noncondensing |
Certifications | CE, FCC, IC |
Software | |
Wi-Fi Standards | 802.11a/b/g Wi-Fi 4/Wi-Fi 5/Wi-Fi 6 |
Wireless Security | WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3*)*Supported With Upcoming Controller Versions |
BSSID | 8 per Radio |
VLAN | 802.1Q |
Advanced QoS | Per-User Rate Limiting |
Guest Trafc Isolation | Supported |
Concurrent Clients | 300 |
Supported Data Rates (Mbps) | |
802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (Wi-Fi 4) | 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) |
802.11b | 1, 2, 5.5, 11 Mbps |
802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11ac (Wi-Fi 5) | 6.5 Mbps to 866.7 Mbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80) |
802.11ax (Wi-Fi 6) | 6.3 Mbps to 1.2 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80) |
“
