ZKTECO TS2000 BRIDGE TRIPOD TURNSTILE SERIES IN/OUT

ZKTECO TS2000 BRIDGE TRIPOD TURNSTILE SERIES

Product Overview

The TS2000 series is a bridge-type tripod turnstile, meaning it has a compact, streamlined cabinet design with a horizontal top surface. It operates using a semi-automatic mechanism, where the arm unlocks upon authorization and rotates manually.

It supports bi-directional access control, allowing both entry and exit management with integration into modern access systems.

Product Description

The ZKTeco TS2000 Bridge Tripod Turnstile is a reliable and cost-effective pedestrian access control system designed to manage entry and exit (IN/OUT) in secure environments. Featuring a three-arm rotating barrier (tripod mechanism), it ensures controlled passage of one person at a time, making it ideal for areas requiring basic yet effective security control.

This model is widely used in offices, factories, schools, public transport stations, and commercial facilities where moderate to high pedestrian flow needs to be regulated.

MODEL DESCRIPTION

Key Features

1. Tripod Arm Mechanism
Three rotating arms ensure one-person-at-a-time access, preventing unauthorized entry and tailgating.

2. Durable Stainless Steel Construction
Made from 304 stainless steel, offering durability, corrosion resistance, and long operational life.

3. Bi-Directional Operation (IN/OUT)
Supports:

• Entry only
• Exit only
• Both directions simultaneously

4. Compact Bridge Design
Slim and space-saving design, ideal for installations where space is limited.

5. Access Control Integration
Compatible with:

• RFID card readers
• Biometric devices (fingerprint & face recognition)
• QR code and ticketing systems

6. Anti-Tailgating Security
Allows only one person per rotation, enhancing security control.

7. LED Direction Indicators
Visual indicators guide users for smooth entry and exit.

8. Emergency Drop Arm Function
Arms automatically drop down during power failure or emergency, allowing free passage for evacuation.

9. Low Power Consumption
Energy-efficient design suitable for continuous operation.

10. Easy Installation & Maintenance
Simple structure ensures quick installation and minimal maintenance.

Technical Specifications (Typical for TS2000 Series)

• Model: TS2000 Series
• Type: Bridge Tripod Turnstile
• Material: 304 Stainless Steel
• Passage Width: ~550 mm
• Throughput: 25–30 persons per minute
• Operation: Semi-automatic (manual push after unlock)
• Power Supply: 100–240V AC
• Control Interface: Dry contact / RS485
• Operating Temperature: -20°C to +60°C
• Direction Control: Bi-directional (IN/OUT)
• Emergency Mode: Drop-arm feature

MODEL SPECIFICATION

OVERALL SPECIFICATIONS

Applications

• Corporate offices and workplaces
• Factories and industrial sites
• Schools and universities
• Metro stations and bus terminals
• Gyms and clubs
• Government buildings
• Construction site access control

Frequently Asked Questions (FAQs)

1. What is the TS2000 turnstile used for?
It is used to control pedestrian entry and exit in secure areas.

2. Is it fully automatic?
No, it is semi-automatic—the arm unlocks electronically but rotates manually.

3. Can it integrate with biometric systems?
Yes, it supports fingerprint, face recognition, RFID, and QR systems.

4. Does it prevent tailgating?
Yes, the tripod design ensures one-person passage at a time.

5. What happens during power failure?
The arms drop automatically for free passage.

6. Is it suitable for outdoor use?
Yes, its stainless steel body makes it suitable for both indoor and outdoor environments.

7. How fast is the throughput?
Approximately 25–30 persons per minute.

8. Does it require maintenance?
Very minimal maintenance is required.

9. What makes it different from flap barriers?
It is more affordable and simpler, but flap barriers offer faster and more modern operation.

10. Where is it commonly installed?
In offices, factories, schools, and public transport areas.

Why Choose ZKTeco TS2000?

The TS2000 series is a cost-effective and durable solution for managing pedestrian flow. It offers reliable access control, simple operation, and strong build quality, making it ideal for organizations that need basic security with high efficiency.
