Camera

Image Sensor

1/3″ CMOS

Max. Resolution

2880 (H) × 1620 (V)

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Illumination Distance

Up to 30 m (98.43 ft) (IR);
Up to 30 m (98.43 ft) (Warm Light)

Illuminator On/Off Control

Auto

Illuminator Number

2 (IR LED); 2 (Warm light)

Angle Adjustment

Pan: 0°–355°;
Tilt: 0°–90°

Lens

Max. Aperture

F1.6

Field of View

H: 78°; V: 40°; D: 93°

Intelligence

Vehicle Detection

Yes

Human Detection

Yes

Video

Video Compression

H.265

Video Frame Rate

Main stream: 2880 × 1620@(1-25/30 fps)
sub stream: 640 × 360@(1-25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.

Resolution

5M (2880 × 1620); nHD (640 × 360)

Video Bit Rate

H.265: 80 kbps–4096 kbps

Day/Night

Auto(ICR)/Color/B/W

WDR

DWDR

Motion Detection

Yes

Smart Illumination

Yes

Image Rotation

0°/180°

Audio

Built-in MIC

Yes, built-in Mic

Built-in Speaker

Yes, built-in speaker

Audio Compression

G.711a

Network

Network Port

RJ-45 (10/100 Base-T)

Wi-Fi

IEEE 802.11b/g/n/ax 2.412-2.472 GHz, 2.4 G

Storage

Micro SD card (up to 256 GB)

Management Software

DMSS

Mobile Client

iOS;Android

Certification

Certifications

CE

Power

Power Supply

12 VDC, 1 A

Power Consumption

Basic: 1.68 W
Max.: 4.56 W (H.265+warm light on)

Environment

Operating Temperature

–20 °C to +50 °C (–4 °F to +122 °F)

Operating Humidity

≤95%

Structure

Casing Material

Plastic

Product Dimensions

116 mm × 138 mm × 139 mm (4.57″ × 5.43″ × 5.47″) (L × W × H)

Net Weight

425 g (0.94 lb)

Operating Humidity

≤95%

Structure

Product Dimensions

140.5 mm × Φ111.0 mm (5.53″ × Φ4.37″)

Net Weight

0.5 kg (1.10 lb)

Gross Weight

1 kg (2.20 lb)
