UBIQUITI US-8-150W DESCRIPTION
| • Model No | US-8-150W |
| • Forwarding Rate | 14.88 Mpps |
| • SFP Ports | (2) 1 Gbps SFP Ethernet Ports |
| • Gigabit RJ45 Ports | (8) 10/100/1000 Mbps RJ45 Ethernet Ports |
| • Switching Capacity | 20 Gbps |
| • PoE Mode | 150W |
| • Sound Level* (dBr) | 0.5 (fanless) |
Expand and power your network with the UniFi® Switch 8 150W, part of the Ubiquiti Networks® UniFi Enterprise System. The UniFi® Switch 8 150W is a fully managed PoE Gigabit switch, delivering robust performance and intelligent switching for enterprise networks. The UniFi® Switch 8 150W offers the flexibility of (8) Gigabit RJ45 ports with auto-sensing PoE or 24V Passive PoE to power your UniFi access points and other PoE devices. Additionally, two SFP ports provide uplink and fiber connectivity options capable of delivering speeds of up to 1 Gbps each. The UniFi® Switch 8 150W supports up to 10 Gbps total, a non-blocking line rate.
Features:
- (8) Gigabit RJ45 Ethernet Ports
- (2) 1G SFP Fiber Ports
- Auto-Sensing IEEE 802.3af/at PoE
- Configurable 24V Passive PoE
- 10 Gbps Total, Non-Blocking Line Rate
- Managed with UniFi Application
PRODUCT SPECIFICATIONS
| US-8-150W | |
| Dimensions | 204 x 43 x 235 mm
(8.03 x 1.69 x 9.25?) |
| Weight
With Mount Brackets |
1.65 kg (3.64 lb)
1.73 kg (3.81 lb) |
| Networking Interfaces | (8) 10/100/1000 Mbps RJ45 Ports
(2) 1 Gbps SFP Ports |
| Management Interfaces | Ethernet In-Band |
| Power Method | 100-240VAC/50-60 Hz, Universal Input |
| Power Supply | AC/DC, Internal, 150W DC |
| Max. Power Consumption
Including PoE Output Excluding PoE Output |
150W
20W |
| Processor Specs | ARM Cortex-A9 400 MHz |
| Memory Information | 256MB DDR3 |
| Code Storage | 32 MB NOR Flash |
| Line Rate | 10 Gbps, Non-Blocking |
| LEDs
System RJ45 Data Ports SFP Data Ports |
Status
PoE; Link/Speed/Activity Link/Speed/Activity |
| PoE Output (RJ45 Ports) | IEEE 802.3at/af 2-Pair ( 1, 2; -3, 6);
Passive 24V/0.7A 2-Pair ( 4, 5; -7, 8) |
| ESD/EMP Protection | ± 24kV Air, ± 24kV Contact |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
“
