DAHUA ISC-M6550A X-ray Baggage Scanner Inspection System

Original price was: ₨ 3,500,000.Current price is: ₨ 3,200,000.

Product Features

Uses X-ray to generator images of packaged items passing on the conveyor belt, and checks the shape and size of packaged items.
> Displays images of the packages with enhanced effects, such as Penetration enhancement, super enhancement, high density alert and image scanning.
> Security screening mode and video surveillance mode.
> Recognizes dangerous items such as knives, bottled liquid, spray cans, guns and lighters from scanned images.
> Set danger levels for suspect items and link alarms such as voice prompt, sound and light alarm and conveyor belt stopping.
> Displays AI overlay on suspected objects. The AI overlay box moves with the package.

Compare

Add to wishlist

Shipping & Delivery

Courier delivery

Our courier will deliver to the specified address. Delivery charges are Rs. 500 plus as per distance basis

2-3 Days

Minimum Rs. 500

In case of advance payment

Free delivery available

In case Cash on delivery

Minimum Rs. 1,500 confirmation deposit is mandatory

2-3 Days

Free Delivery

Minimum Rs. 500

Warranty as per Manufacturer

More details

Free 7-Days return

More details

Description

ISC-M6550A X-ray Baggage Scanner Inspection System

Product Description

The Dahua ISC-M6550A X-Ray Baggage Scanner is an advanced intelligent security screening system designed for high-accuracy inspection of carry-on luggage, parcels, and small cargo items without opening them. It uses modern X-ray imaging technology combined with AI-based object recognition to detect prohibited items such as weapons, explosives, liquids, and other security threats.

This model is widely used in airports, government buildings, metro stations, border control points, and high-security facilities, where fast and reliable baggage screening is required.

Key Features

1. Intelligent X-Ray Imaging System
Uses a single-energy X-ray generator to produce high-quality internal images of scanned baggage with shape and material analysis.

2. AI-Based Threat Detection
Automatically identifies suspicious items such as:

Knives and weapons
Bottles and liquids
Guns and lighters
Spray cans and dangerous objects

3. High-Resolution Image Enhancement
Supports advanced image processing including:

Penetration enhancement
High-density alert
Super enhancement
Color/edge processing
AI overlay tracking

4. Dual Monitoring Cameras
Equipped with built-in cameras to monitor both:

Entry of baggage
Exit and scanning process for security tracking

5. Conveyor Belt Scanning System
Automatically moves baggage through the tunnel for continuous and efficient screening.

6. Alarm & Danger Level System
Configurable alerts including:

Audio warning
Visual alarm
Conveyor stop function
Risk-level classification (safe / warning / high risk)

7. Data Storage & Reporting
Stores scanned images and allows:

Search by time or object type
Export of security reports
Audit and investigation support

8. User Access Control (Fingerprint Login)
Supports biometric login to ensure only authorized operators can use the system.

9. Network Integration Support
Can be connected via LAN/TCP-IP for centralized monitoring and control.

10. High Reliability Industrial Design
Built for continuous operation in high-traffic environments with stable performance and low maintenance requirements.

Technical Specifications (Typical)

System

CPU

Intel quad-core processor

RAM

Operating System

Embedded Linux OS

User Interface

Local GUI (full functions); Web interface

Basic

Tunnel Size

650 mm × 500 mm (25.59” × 19.69”)

X-ray Tube Anode Voltage

80 kv

X-ray Tube Cooling

Sealed oil bath with forced air

Wire Resolution

40AWG (0.0787 mm)

Penetration(steel)

8 mm

Leakage Dose-rate

≤ 0.9μSv/h (μGy/h)

Noise Level

≤ 65 dB

Conveyor Speed

0.2 m/s

Maximum Belt Load

80 kg (176.36 lb)

Conveyor Hight

approx. 666 mm (26.22”)

Current Leakage

≤ 0.25 mA

Film Safety

ISO 1600 (33 DIN)

Intelligent Analysis

Preview

Real-time display of X-ray package image and camera image; real-time item intelligent analysis

Item Recognition

Recognizes items and displays AI overlay; the AI overlay box moves with packages

Recognition Types

Recognizes 21 types of objects: Guns, fireworks, spray

cans, knives, axes, scissors, nail polish, bottled liquids, glass bottles, thermos bottles, plastic bottles, handcuffs, nightsticks, brass knuckles, lighters, tools, electronic products, mobile phones, powerbanks, laptops and umbrellas

Danger Levels

High risk, warning, and safe (supports custom configuration according to types of objects)

Event Linkage

I/O alarm, voice prompt, platform alarm can be triggered according to danger levels

Image Storage

Stores as much as 1 million images with information on their danger levels and the types of objects detected. Original and analyzed images can both be viewed.

Baggage Search

Search, play back, and export baggage images and linked videos according to time, objects type and more

Report Search

Generate and export reports according to time and object types

Backup

USB/Network

Performance

Self-inspection

Automatically detects system failures and prompts error codes

Image Processing

Enhancement functions include color/black and white, local enhancement, super enhancement, edge enhancement, image scanning, inverse, Penetration enhancement, light, dark, high density alert, AI overlay, vertical flip, pseudo color and more

Image playback

Supports playback of 30 images

Image Zooming

Zoom in X-ray images up to 64x. Drag the focus position using a mouse or direction- keys

Device Diagnosis

Supports diagnosis of key components such as the detector, motor, IR sensor

Detection Configuration

Key function configuration; image display configuration (vertical flip and max zoom times), scan mode configuration (double direction, forward scan), baggage counter configuration and person-package linkage configuration

Basic

Graphics Output

1-channel HDMI video output: Up to 1920 (H) × 1080 (V) @60 Hz

Monitor

1 × 21.5″ monitor

Video Input (Network)

4-channel input (max 4K); 4-channel IPC

Recording Mode

4-channel input (max 4K); 4-channel IPC; supports H.265, H.264, PCM and MPEG4

Audio output

1-channel MIC Out (3.5 mm)

Built-in Disks

Supports up to 6 T SATA disks and configures 1 T disk by default

Ethernet Ports

1 × RJ-45 10M/100M/1000M self-adaptive Ethernet ports; 2 × RJ-45 10M/100M Ethernet ports

Internet Protocols

HTTP, HTTPS, TCP/IP, UDP, RTSP, IPv4, NTP, DHCP, DNS, IP Filter, IP Search (Support Dahua IP camera, DVR and more)

Interoperability

ONVIF, SDK and more

Port

RS 232 Port

1-channel RS 232 port

Power port

1-channel port for monitor power supply
12 V 1A power output

USB Port

2-channel USB3.0 for controlling the operation keyboard and mouse

Display Port

2-channel HDMI outputs (same source)

Alarm Port

2-channel alarm output; 2-channel alarm input

Emergency Stop Button

2 (on the machine body)

Power Button

1 (on the machine top)

Key Switch

1 (on the machine top)

Indicator light

On the machine:
Power indicator: Turns solid green when the machine is working and flashes during updates and when an error occurs
X-ray indicators: the red light is always on when X-ray is turned on, but not when X-ray is turned off
Key switch indicator: The green light is always on when the key is turned to on, but not on when the key is turned to off

Regular

Power Supply

220–240 VAC, 50/60 Hz; 100–130 VAC, 50/60 Hz (optional)

Typical Power Consumption

220 W

Maximum Power Consumption

650 W

Intelligent Temperature Control

Detects the temperature of main board and HDD and automatically adjusts fan speed to make it work stably and quietly

Operating Temperature

0 °C to +45 °C (32 °F to +113 °F)

Operating Humidity

0%–95% RH (non-condensing)

Storage Temperature

–20 °C to +70 °C (–4 °F to +158 °F)

Storage Humidity

0%–95% RH (non-condensing)

Dimensions

2,024 mm × 915.6 mm × 1401.8 mm (79.69” × 36.05” × 55.19”)

Package Size

2175 mm × 1195 mm × 1630 mm (85.63” × 47.05” × 64.17”)

Net Weight

420 kg (925.94 lb)

Gross Weight

520 kg (1,146.4 lb)

Installation Mode

Floor installation

Control Console Size

1200 mm × 750 mm × 600 mm (47.2″ × 29.5″ × 23.6″)

Control Console Package Size & Weight

1276 mm × 376 mm × 200 mm (50.24″×14.80″×7.87″), 38.5 kg (84.88 lb)

Applications

Airports and aviation security
Government and embassy buildings
Metro and railway stations
Customs and border control
Hotels and conference centers
Corporate security checkpoints
Public event venues and stadiums

Frequently Asked Questions (FAQs)

1. What is the DAHUA ISC-M6550A used for?
It is used for scanning luggage and parcels to detect security threats like weapons, explosives, and restricted items.

2. Does it use AI detection?
Yes, it has AI-based object recognition that identifies dangerous items automatically.

3. What size baggage can it scan?
It supports medium-sized luggage with a 650 × 500 mm tunnel opening.

4. Can it store scan data?
Yes, it stores images and allows search, playback, and report generation.

5. Is it suitable for airports?
Yes, it is widely used in airports, metro stations, and high-security checkpoints.

6. Does it have alarm features?
Yes, it supports audio alarms, visual alerts, and conveyor stopping based on threat level.

7. How many cameras does it have?
It includes dual built-in cameras for monitoring entry and exit of baggage.

8. Can it be connected to a network?
Yes, it supports TCP/IP network integration for centralized monitoring.

9. Is operator access secure?
Yes, it supports fingerprint-based login authentication.

10. What types of items can it detect?
It can detect guns, knives, liquids, aerosols, and other prohibited objects.
