Black Copper BC-8850-AR Freedom Description
Product Description
The BC-8850-AR features the accuracy of optical laser, with a compact, ergonomic and affordable design. The BC-8850-AR features technical advancements that eliminate internal vibrating mirrors and moving parts for better shock absorption,longevity and durability. Black Copper barcode scanners combine high performance, accuracy, and true value. This USB version offers a best-in-class solution for retail, point of sale, Office, Light Industrial, Warehouse, Libraries, Medical, Legal office, Government, marketing and any repetitive application where time and precision are critical factors in helping businesses streamline their workflow.
Impact Resistant
With the scanner’s durable CCD sensor engine design and its durable ABS material, it makes the BC-8850-AR less likely to become damaged due to accidental drops from as high as 1.2m off the ground.
Superior CCD Sensor with Scanning Performance at 350 Scans Per Second
The CCD sensor can scan the majority of 1D symbologies at a comfortable distance of up to 12 inches away.The 350 scans per second rate offers fast and accurate scanning results for faster productivity and reliability.
Scanning Range
The CCD sensor allows a wider and longer scan field of up to 12 inches of scanning range.
Specification
| Operating indicators | Visual:2 LEDs(Red,Blue)
Non-visual:Buzzer |
| Communications | USB(Ver. 1.1 HID Keyboard) |
| Sensor resolution | 752*480 pixels |
| Light source | 632nm LEDs |
| Aiming light | 617nm LEDs |
| Scan method | CMOS array sensor |
| Fixed focus distance | 39°(H)x25°(V) |
| Motion capability | <= 63.5cm/25in/s |
| Scan rate | Up to 60 fps |
| Scan reading angle | Yaw:±30° or greater
Pitch :±70° or greater Roll:±45° |
| Min. resolution, C39 at PCS 0.9) | 5mil (0.127mm) |
| Min.print contrast | Minimum 25% minimum reflective difference |
| Image file formats | BMP,TIFF and JPEG |
| Voltage | 5 VDC±10% @260mA |
| Current consumption | 120mA (typical use), max.250mA |
| Temperature | 0°C to 40°C (operation),
-40°C to 70°C (storage) |
| Humidity | 5% to 95% , non-condensing |
| Ambient light immunity | 86,000 lux (direct sunlight), 1600lux (Indoor light) |
| Drop test | 1.8 m (6 ft) drop onto concrete surface |
| Protection rate | IP54 |
| MBTF | 53,310hours |
| Dimensions | 90.5 x 69.8 x 160 mm/ 3.56 x 2.75 x 6.30 in (d x w x h) |
| Weight body | 193g/ 6.81 oz (include. cable) |
| Case | PC,Black or Grey |
| Product Compliance | CE, FCC, IEC 60825-1 Class 2, GB7247.1-2001 |
| Enclosed items | Cable(USB,RS232),User Guide,DC power supply (RS232) |
| Application and Solution | Self-Service Machine, Medical And Diagnosis Equipment, Lottery Machine, Automatic Manufacture Line, File Management System, Etc |
| 1D | UPC/EAN, UPC/EAN with supplementals, Bookland EAN, ISSN, UCC Coupon Extended Code, Code 128, GS1-128, ISBT 128, Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32, Code 93, Code 11, Matrix 2 of 5, Interleaved 2 of 5, Discrete 2 of 5, Codabar, MSI, Chinese 2 of 5, GS1 DataBar variants, Korean 3 of 5, ISBT Concat |
| 2D | PDF417, MicroPDF417, Composite Codes, TLC-39, Data Matrix, Maxicode, QR Code, MicroQR, Aztec |
