Black Copper 16 Channel Fiber Optic Media Converter

”

BLACK COPPER 16 CHANNEL FIBER OPTIC MEDIA CONVERTER DESCRIPTION

Features:

8bit digital code and non-compression type video transmission

Support any high-resolution video signal

Automatic compatible PAL, NTSC, and SECAM video system

Power supply and other parameter state indications can monitor the operation condition of the system

Support no-damage regenerative trunk of video

With constant input optical power, and large dynamic range, and it is unnecessary to implement the adjustment of spot electrics or optics when using

Special ASIC design

Industry-grade of operating temperature from -20°C to 75°C, which is applied to the different working environments

Hot-swap function

Specifications:

Optical Characteristics

Fiber connector FC/PC

Transmission distance 550M-80KM(20KM for single mode fiber)

Wavelength 1310/1550nm

Video Characteristics

Port 16

Video Interface BNC

Video-Input/Output Impedance 75?(unbalanced)

Video-Input/Output Voltage 1V pp(typical value) 1.5V pp(max value)

The bandwidth of Video 5Hz to 7.5MHz

Automatic Compatible Video System PAL SECAM NTSC

Differential gain (10%-90%APL) DG<1%(typical value)

Differential phase (10%-90%APL) DG<0.7%(typical value)

Weighted Signal-to-Noise Ratio >=70dB

Data Characteristics

Interface Port Standard Terminal Lead

Interface Signal Type RS-232/RS-422-485/manchester

Code Rate 0-400Kbps

BER < 10-9

Other Normal Characteristics

Operating Temperature -20~ 75 °C

Humidity 0~95% (no condensing)

Operating Voltage DC 5V/1A

MTBF >=10,0000Hours”
