ATC-XX230V AX1800 Wireless Gigabit GPON HGU with VoIP
Original price was: ₨ 26,000.₨ 23,000Current price is: ₨ 23,000.
Short Description
The ATC-XX230V AX1800 Wireless Gigabit GPON HGU is a high-performance fiber broadband gateway featuring Wi-Fi 6 AX1800, integrated VoIP, Gigabit Ethernet connectivity, and GPON Class B+ support. It delivers wireless speeds of up to 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz, with HT80 technology, making it suitable for high-speed FTTH internet, home, office, and ISP deployments.
Shipping & Delivery
-
Courier delivery
Our courier will deliver to the specified address. Delivery charges are Rs. 500 plus as per distance basis
2-3 Days
Minimum Rs. 500
-
In case of advance payment
Free delivery available
-
In case Cash on delivery
Minimum Rs. 1,500 confirmation deposit is mandatory
2-3 Days
2-3 Days
Free Delivery
Minimum Rs. 500
-
Warranty as per Manufacturer
-
Free 7-Days return
Description
ATC-XX230V AX1800 Wireless Gigabit GPON HGU with VoIP
Product Description
The ATC-XX230V AX1800 Wireless Gigabit GPON HGU with VoIP combines fiber-optic connectivity, high-speed dual-band Wi-Fi, Gigabit Ethernet, and voice services in a single device.
Powered by an Econet chipset, the device supports G.984.x GPON standards and Class B+. Its AX1800 dual-band wireless capability provides up to 574 Mbps at 2.4 GHz and 1201 Mbps at 5 GHz, with HT80 support for efficient wireless performance.
For wired networking, the ATC-XX230V provides 1 × Gigabit Ethernet WAN/LAN port and 3 × Gigabit Ethernet LAN ports. It also includes an RJ11 FXS port for VoIP, a USB 2.0 port, and an SC/APC GPON optical port.
The device supports advanced network management and service features including QoS, IGMP, OMCI, TR-069 with TR-098/TR-181 support, EasyMesh, Aginet APP, and cloud support, making it suitable for modern managed broadband and FTTH networks.
⭐ Key Features
- 🚀 AX1800 Wi-Fi 6 dual-band wireless
- 📶 574 Mbps at 2.4 GHz
- ⚡ 1201 Mbps at 5 GHz
- 📡 HT80 support
- 🌐 GPON G.984.x support
- 🔌 Class B+ GPON
- 🔗 1 × Gigabit WAN/LAN port
- 🔗 3 × Gigabit LAN ports
- ☎️ 1 × RJ11 FXS VoIP port
- 💾 1 × USB 2.0 port
- 🔦 1 × SC/APC GPON port
- 📡 4 × Fixed Antennas
- ⚙️ QoS & IGMP support
- 🔧 OMCI management
- ☁️ TR-069, TR-098 & TR-181 support
- 📲 EasyMesh support
- 📱 Aginet APP support
- ☁️ Cloud support
⚙️ Key Specifications
| Specification | Details |
|---|---|
| Model | XX230V |
| Product Type | AX1800 Wireless Gigabit GPON HGU |
| Chipset | Econet |
| GPON Standard | G.984.x |
| GPON Class | B+ |
| Wi-Fi Technology | Wi-Fi 6 |
| 2.4 GHz Speed | 574 Mbps |
| 5 GHz Speed | 1201 Mbps |
| Wireless Technology | HT80 |
| WAN/LAN Port | 1 × Gigabit Ethernet |
| LAN Ports | 3 × Gigabit Ethernet |
| VoIP Port | 1 × RJ11 (FXS) |
| USB Port | 1 × USB 2.0 |
| GPON Interface | 1 × SC/APC |
| Antennas | 4 × Fixed Antennas |
| QoS | Supported |
| IGMP | Supported |
| OMCI | Supported |
| TR-069 | Supported |
| TR-098 / TR-181 | Supported |
| EasyMesh | Supported |
| Mobile App | Aginet APP |
| Cloud Support | Supported |
Applications
The ATC-XX230V is suitable for:
- Fiber Internet Service Providers
- FTTH Deployments
- Home Broadband Networks
- Office Networks
- Hotels & Guest Houses
- Small & Medium Businesses
- Managed Broadband Services
- VoIP Broadband Networks
Advantages
- High-speed Wi-Fi 6 connectivity
- AX1800 dual-band wireless performance
- Integrated GPON fiber connectivity
- Gigabit Ethernet networking
- Built-in VoIP support
- Four fixed antennas
- EasyMesh support for expanded wireless coverage
- Advanced ISP management capabilities
- TR-069/TR-098/TR-181 support
- Aginet APP and cloud support
